| Conductor | Insulation | Electrical Characteristic | packing | ||||
| AWG | Conductor construction NO×φmm |
Diameter mm | Insulation Thickness mm | Over Diameter mm | Realst.max Cuc.c 20ºC ohm/km |
Permissiblle ampacity 20ºC-AMR | mt/coils |
| 26 | 7×0.16 | 0.49 | 0.3 | 1.09 | 143.00 | 3.15 | 610 |
| 24 | 7×0.20 | 0.61 | 0.3 | 1.21 | 89.30 | 5.04 | 305 |
| 22 | 19×0.15 | 0.76 | 0.3 | 1.36 | 56.40 | 7.98 | 305 |
| 20 | 19×0.185 | 0.93 | 0.3 | 1.53 | 35.20 | 12.78 | 305 |
| 18 | 19×0.235 | 1.16 | 0.3 | 1.76 | 22.20 | 20.27 | 305 |
